Complete Architectural Plans for a Modern A-Frame Cabin (44 Pages)
This is a full set of architectural plans for a modern and luxurious 64′ x 50′ A-frame cabin with a stylish and comfortable interior design.
Key Features:
- Two-story design with 2,415 sq. ft. of heated living space.
- Perfect for family homes, AirBnB rentals, or construction site housing.
- A-frame homes are affordable, energy-efficient, and easier to build compared to traditional homes.
- Makes a great gift for occasions like birthdays or Father’s Day.
What’s Included:
You’ll receive a PDF file (no CAD files—available for purchase separately) with:
- Materials List
- Floor Plans
- Elevation Plans
- Roof Plan
- Electrical Plan
- Plumbing Plan
- Foundation/Roofing Details
- Door/Window Schedule
- Fully dimensioned and labeled plans
- Porch details
Specifications:
- Total Building Area: 3,106.88 sq. ft.
- Building Footprint: 2,944.56 sq. ft.
- Living Area: 2,415.98 sq. ft.
- Porch Area: 671.32 sq. ft.
- Number of Stories: 2
- Foundation: Reinforced Concrete
- Roof Type: Wood Truss, 57° pitch
- Max Ridge Height: 31′-4 5/8″
- Main Ceiling Height: 10′-1″
- Bedrooms: 2
- Full Bathrooms: 3
First Floor Details:
| Space |
Area (sq. ft.) |
| Master Bedroom |
208.68 |
| Master Closet |
90.89 |
| Master Bathroom |
113.64 |
| Kitchen/Dining |
316.93 |
| Living Room |
244.52 |
| Office |
101.46 |
| Laundry |
74.32 |
| Foyer |
41.34 |
| Hall |
231.25 |
| Mechanical Room |
74.32 |
| Bathroom |
134.22 |
| Covered Patios |
276.10, 280.58, 114.64 |
Second Floor Details:
| Space |
Area (sq. ft.) |
| Bedroom 2 |
327.22 |
| Hall |
38.37 |
| Bathroom |
93.04 |
This beautifully designed A-frame cabin combines modern style with functionality, making it a great investment for personal or rental purposes.
